EnGenius AP Cloud5 2×2 Wallplate

Cloud Managed 11ac Wave 2 Wireless Indoor Access Point

ECW115

kr 1,456.00 1456.0 NOK kr 1,456.00

kr 1.00

Wi-Fi generation
- Wi-Fi 5
Radio hertz
- 2.4 GHz & 5 GHz
Radio chains
- 2×2
Network interface
- 1G
Power-over-Ethernet
- 802.3af/at
Max concurrent users
- 128 per radio
Mounting type
- Wall plate
Series
- Cloud

This combination does not exist.

Add to cart

Wi-Fi generation: Wi-Fi 5

Radio hertz: 2.4 GHz & 5 GHz

Radio chains: 2×2

Network interface: 1G

Power-over-Ethernet: 802.3af/at

Max concurrent users: 128 per radio

Mounting type: Wall plate

Series: Cloud

Operating Frequency
Dual-Radio Concurrent 2.4GHz & 5GHz
Operation Modes
Managed mode: AP, AP Mesh, Mesh
Frequency Radio
2.4 GHz: 2400 MHz ~ 2482 MHz
5 GHz: 5150 MHz ~ 5250 MHz, 5250 MHz ~ 5350 MHz, 5470 MHz ~ 5725 MHz,5725 MHz ~ 5850 MHz
Transmit Power
Up to 17 dBm on 2.4GHz
Up to 17 dBm on 5GHz
(Maximum power is limited by regulatory domain)
Radio Chains
2 × 2:2
SU-MIMO Capability
Two(2) spatial stream Single User (SU) MIMO for up to 400 Mbps wireless data rate with VHT40 bandwidth to a 2×2 wireless device under the 2.4GHz radio.
Two(2) spatial stream Single User (SU) MIMO for up to 867 Mbps wireless data rate with VHT80 to a 2×2 wireless device under the 5GHz radio.
MU-MIMO Capability
Two (2) Spatial Stream MU-MIMO up to 867 Mbps wireless data rate for transmitting to two (2) streams MU-MIMO capable wireless devices under 5GHz simultaneously.
Supported Data Rates
2.4 GHz: Max 400 (MCS0 to MCS11, NSS = 1 to 2)
5 GHz: Max 867 (MCS0 to MCS11, NSS = 1 to 2)
802.11b: 1, 2, 5.5, 11
802.11a/g: 6, 9, 12, 18, 36, 48, 54
802.11n: 6.5 to 300 Mbps (MCS0 to MCS15) (Additional 25% bandwidth when enabling 256-QAM uner HT40)
802.11ac: 6.5 to 867 Mbps (MCS0 to MCS9, NSS = 1 to 2)
Supported Radio Technologies
802.11a/g/n/ac: Orthogonal Frequency-Division Multiplexing (OFDM)
802.11b: Direct-Sequence Spread Spectrum (DSSS)
802.11n/ac: 2×2 MIMO with 2 Streams
Channelization
802.11ac Supports Very High Throughput (VHT)—VHT 20/40/80 MHz
802.11n Supports High Throughput (HT)—HT 20/40 MHz
802.11n Supports High Throughput (HT) Under the 2.4 GHz Radio—HT 40 MHz(256-QAM)
802.11n/ac Packet Aggregation: A-MPDU, A-SPDU
Supported Modulation
802.11ac: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM
802.11a/g/n: BPSK, QPSK, 16-QAM, 64-QAM
802.11b: BPSK, QPSK, CCK
DFS Certification
N/A
AirGuard (WIPS/WIDS)
N/A
Zero-wait DFS
N/A
Dedicated Scanning Radio
N/A
Max Concurrent User
128 Per radio
Client Balancing
Yes
Auto Channel Selection
Yes

Multiple BSSID
8 SSIDs on both 2.4 GHz and 5 GHz bands
VLAN Tagging
Supports 802.1q SSID-to-VLAN Tagging
Cross-Band VLAN Pass-Through
Management VLAN
Spanning Tree
Supports 802.1d Spanning Tree Protocol
QoS (Quality of Service)
Compliance With IEEE 802.11e Standard
WMM
SNMP
v1, v2c, v3
MIB
I/II, Private MIB
Fast Roaming
802.11r/k
Wireless Security
WPA2-PSK
WPA2-Enterprise
WPA3-PSK
WPA3-Enterprise
Hide SSID in Beacons
Wireless STA (Client) Connected List
Client Isolation
Client Access Control
Interface
IPv4, IPv6
Local Web Access
Supports HTTP or HTTPS

Temperature Range
Operating: 32ºF~104ºF (0 ºC~40 ºC)
Storage: -40 ºF~176 ºF (-40 ºC~80 ºC)
Humidity (non-condensing)
Operating: 90% or less
Storage: 90% or less

Weight
225 g
Dimensions
Width: 140 mm
Length: 90 mm
Height: 40 mm
Package Contents
1 – ECW115 Cloud Managed Indoor Access Point
1 – Junction Plate (short)
1 – Junction Plate (tall)
1 – Mounting Screw Kit
1 – Product Card
Regulatory Compliance
FCC
CE
IC

Data Sheets, Quick Guides, White Papers, Firmware and others for ECW115:DOWNLOADS
